VNH9013YTR New And Original SSOP36 Integrated Circuit
ISO9001.pdf
| Product Technical Specifications | |
| EU RoHS | Compliant with Exemption |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.01 |
| SVHC | Yes |
| SVHC Exceeds Threshold | Yes |
| Automotive | Yes |
| PPAP | Unknown |
| Type | Motor Driver |
| Motor Type | DC Motor |
| Output Configuration | H-Bridge |
| Maximum Output Current (A) | 40 |
| Operating Supply Voltage (V) | 80(Max) |
| Maximum Operating Supply Voltage (V) | 80 |
| Maximum Operating Temperature (°C) | 175 |
| Mounting | Surface Mount |
| Package Height | 2.4(Max) |
| Package Width | 7.6(Max) |
| Package Length | 10.5(Max) |
| PCB changed | 36 |
| Standard Package Name | SOP |
| Supplier Package | PowerSSO EP |
| Pin Count | 36 |
| Lead Shape | Gull-wing |
Introduction: The VNH9013YTR is a motor driver chip designed for driving DC motors. It features dual half-bridge outputs and input control for PWM signals. Its high voltage capability, thermal protection, and reverse current protection are some of its key features. The VNH9013YTR can operate in high load conditions, making it ideal for applications such as power tools, electric toys, and robots.
Specifications:
| Parameter | Value |
| Maximum output current | 12A |
| Operating voltage range | 5.5V to 36V |
| Internal current sensing resistor | 50mΩ |
| Static current | 5mA |
| Operating temperature range | -40°C to 150°C |
Applications:
The VNH9013YTR is primarily used for driving DC motors in various applications such as electric toys, power tools, and robots. It is ideal for applications that require high load operation and reliable protection features.
Other Recommended Models: Other recommended motor driver chips that can be used in conjunction with the VNH9013YTR include the DRV8833, L298N, and TB6612FNG.
Conclusion: The VNH9013YTR motor driver chip is a reliable and versatile solution for driving DC motors in a variety of applications. Its high voltage capability, thermal protection, and reverse current protection make it an ideal choice for high-load applications. Other recommended motor driver chips can be used in conjunction with the VNH9013YTR to further enhance the performance of your motor control system.
Product Tags:
|
|
VNH9013YTR SSOP36 Integrated Circuit New And Original Images
|
